Description

This model is part of an academic project for aeronautical engineering course. It is an Unmanned Aerial Vehicle (UAV) designed in CATIA V5 for monitoring large areas.The project requirements were long endurance, long range, low speed, high altitude, electric motor and solar power.
The wing airfoil is SG6043 and the tail airfoil is NACA008.The technical drawing is also available with all the dimensions, but see below:

Wing span: 10150mm (10,15 meters)
Wing Root Chord: 680mm
Wing Tip Chord: 580mm
UAV lengh: 3710mm

Don't hesitate to contact me if you need any help with the software, I'll be happy to help.

For any feedback, questions or requests: please contact: fcalsilva19@gmail.com

Features

Animated
Rigged
Ready for 3D Printing
VR / AR / Low-poly
PBR
Textures
Materials
UV Mapping
Unwrapped UVs: Unknown
Geometry: Unknown
Polygons: Unknown
Vertices: Unknown

Tags

Uav Glider Aircraft Drone Plane Engineering Cad Aerodynamic Science
