  • Description
  • Formats
  • An Indoor/outdoor 33kV VCB Switchgear Panels with current ratings from 1250A to 2500A. We use 33kV ABB VD4 VCB for our 33kV Switchgear Panels.
  • Panel shall be constructed with IP4X degree of protection externally and IP2X between compartments.
  • supplied from a single 33kV feeder shall not exceed 45 MVA. If the Network permits a second 33kV feeder, the capacity may be increased to 90MVA.
  • A control and relay panel shall include the following: a) Protective and auxiliary relays required for the protection of transformers and lines. b) Indicating instruments with necessary switches c) Control switch for the remote control of 33 KV circuit breaker.
  • A relay is basically another word for a switch.
  • It could be a switch that turns something on/off or a switch that alternates between two items.
  • In turn, a relay panel is a panel that holds one or more relays that sends power or signal to equipment based upon the input received.
  • relays for protection of respective circuit along with control equipment, meters etc. as necessary for completeness of the protection/control scheme without overcrowding and cramping. c) The 33KV C&R board panels shall be simplex type for accommodating all the control, protection and metering equipment properly.
  • File type: MA,MB,FBX.
  • Number of Polygons: 16237.
  • Number of Vertices: 18580.
  • Number of Tris: 35090.
  • Texture format PNG.
  • Texture resolution 4K.
OBJ (OBJ, filesize: 3.61 MB), MA (Autodesk Maya, filesize: 4.5 MB), FBX (Autodesk FBX, filesize: 4.5 MB)
