5 Axis CNC Head Plans for milling machine-Hot sale 3D print model

$20

License: Content published with the label may not be sold, given, or assigned to another person or entity in the form it is downloaded from the site.

author:

khansolidworks

All content related to this 3D asset—including renders, descriptions, and metadata — is credited to its original author, «khansolidworks». CGhub does not claim copyright ownership over the content used.

Please note these are only Plans, not Physical items!

Convert your 3-Axis router or milling machine into a 5-Axis machining center.

Complete Plans with 3D CAD files in SLDPRT, SLDASM, STEP, IGES format ready to machine on your 3-Axis router ( CNC-6040 ) or milling center.

Also Includes a parts list with supplier links and Detailed Fabrication Instructions.

Specifications:

4-Axis +/- 360-degree rotation.

5-Axis +/- 260 degree rotation.

Spindle 1.5 KW,3 KW. 4.5 KW,5 KW( Air cooled/Water cooled).

4th-Axis control:

Nema34 6NM Stepper/Servo Motor with Planetary Gearbox 10:1 Total torque 60NM

5th-Axis control :

Nema34 12NM Stepper/Servo Motor with Belt and Pulley Mechanism 4:1 Total Torque 48 NM

Material Aluminum 6061 T6.

Extremely Rigid structure design.

Suitable for Milling and Router Machines.

Designed to be machined even on small 3-axis cnc routers eg. 6040 .

Complete tools and parts list included.

Assembly guide included.

Easy to Integrate.

After purchase Technical support . Yes
