Long Endurance Electric UAV 3D model 3D print model

$30

License: Content published with the label may not be sold, given, or assigned to another person or entity in the form it is downloaded from the site.

author:

fcalsilva19

All content related to this 3D asset—including renders, descriptions, and metadata — is credited to its original author, «fcalsilva19». CGhub does not claim copyright ownership over the content used.

This model is part of an academic project for aeronautical engineering course. It is an Unmanned Aerial Vehicle (UAV) designed in CATIA V5 for monitoring large areas.The project requirements were long endurance, long range, low speed, high altitude, electric motor and solar power.
The wing airfoil is SG6043 and the tail airfoil is NACA008.The technical drawing is also available with all the dimensions, but see below:

Wing span: 10150mm (10,15 meters)
Wing Root Chord: 680mm
Wing Tip Chord: 580mm
UAV lengh: 3710mm

Don't hesitate to contact me if you need any help with the software, I'll be happy to help.

For any feedback, questions or requests: please contact: fcalsilva19@gmail.com
