Photovoltaic Solar Panels 3D model

$18

License: Royalty Free

author:

droumbas

All content related to this 3D asset—including renders, descriptions, and metadata — is credited to its original author, «droumbas». CGhub does not claim copyright ownership over the content used.

Fully Parametric Photovoltaic Solar Panel Setup systems Revit Family Model. This is a face based generic model, that can be placed onto any project face ( slab, roof, floor and any other surface ). Large variety of solar panel setups can be created including flat surface mounted systems or flat surface frame mounted.This face based parametric can be placed almost anywhere. Family parameters allow the user to create any variation of solar panel setup necessary. Panel size, mounting angle, panel rows and number of panels per row as well as all materials are parametric.By changing the number and size of panels, all other dimensions are automatically calculated and displayed.

ATTRIBUTES:

Revit Version : 2022
Family Type: Face Based Generic Model
File Extension : .rfa

PARAMETERS:

Panel width
Panel Length
Angle
Rows of panels
Panels per row
Option for surface mounted or frame mounted
All Materials

FAMILY TYPES:All family types pre-built ready to be used are included with this package as a text file that can be automatically read by REVIT. By importing the model, the system opens the list of available family types to be imported. User can select, one or multiple types or even all of them to be imported.

Many more system setups can be created by the user.
