Process Control Cabinet 3D Model Kit 3D model

Name: Process Control Cabinet 3D Model Kit 3D model
Brand: factoriald
SKU: 213055
Price: 50.00 USD
Availability: InStock

$50

License: Royalty Free

author:

factoriald

All content related to this 3D asset—including renders, descriptions, and metadata — is credited to its original author, «factoriald». CGhub does not claim copyright ownership over the content used.

This highly detailed 3D model set is ideal for industrial visualization, factory floor design, simulation training and technical documentation. All key elements of a turnkey control cabinet are included:

Main cabinet enclosure

Metal construction
Engineered doors with hinges, seals and handles

PLC controller

Modular architecture, DIN rail side mounts
Pinout and LED indicators

Motor starters

Contactors, motor starters and thermal relays
Insulated terminal blocks with insulated housings

Protection devices

Circuit breakers RCDs, fuses
DIN rail plug-in and modular types

HMI panel

Touch screen with frame and socket
Cable glands and mounting plate
- Relays and add-on modules
Electromagnetic and solid-state relays
I/O extension module

Specifications:

Formats: FBX, BLEND
Polygonality: high level of detail
Scale: 1:1, units in millimeters

*Benefits of the kit: *

Ready to integrate into any project - from renderings to virtual simulators
All components are grouped and named according to industry standards
Can be edited and customized to fit your application
Complete cabinet model allows you to quickly assemble racks of any size

Add this kit to your 3D element library to speed up your automation and industrial line visualization projects!
