Sanitary Diaphragm Valve TC 2 in 3D model

Description

3D CAD model of a Sanitary Diaphragm Valve TC 2 inch (Ø50.8 mm), designed from scratch for engineering and industrial use.This model includes the manual operating handwheel and the tri-clamp connections on both ends.Accurate and ready for integration into piping projects in the food, beverage, pharmaceutical, and chemical industries, where sanitary design is essential.

Included formats:

.DWG (AutoCAD / Plant 3D)

.STEP (neutral CAD format for Inventor, SolidWorks, Fusion 360, FreeCAD, etc.)

Main benefits:

Save engineering hours with a ready-to-use CAD model.

Clean geometry optimized for sanitary piping projects.

Includes manual handwheel + tri-clamp details.

Compatible with major CAD platforms.

If you need the complete set with all TC diaphragm valve diameters, check my profile for the full package.
