Dipole Antennas:
A simple and widely used type of antenna, consisting of two conductive elements, usually in a straight line. They are used in various applications, including radios, televisions, and wireless communications.Monopole Antennas:
Similar to dipole antennas but with a single element and usually mounted above a ground plane. These are common in mobile devices, car radios, and other portable equipment.Loop Antennas:
Consisting of a loop or coil of wire, these antennas are used for receiving radio waves, particularly in AM radios. They are compact and can be designed in different shapes.Patch Antennas:
A type of antenna with a flat, rectangular design, typically used in GPS devices, mobile phones, and wireless networking equipment. They are known for their low profile and ease of integration into devices.Whip Antennas:
A flexible, rod-like antenna often seen on portable radios, walkie-talkies, and some vehicles. They are simple and provide good omnidirectional coverage.Yagi-Uda Antennas:
While Yagi antennas can be quite large, there are compact versions used for specific applications, such as in Wi-Fi and TV reception, where directional coverage is needed.Microstrip Antennas:
These are small, flat antennas that can be printed onto a circuit board, making them ideal for compact devices like mobile phones, RFID tags, and laptops.Helical Antennas:
These antennas have a helical shape and are used in applications requiring a specific polarization of the signal, such as in satellite communications and GPS devices.
BLEND (Blender, filesize: 82.6 MB), OBJ (OBJ, filesize: 33.6 MB), FBX (Autodesk FBX, filesize: 12.8 MB)
