Steel Pedestrian Bridge-Rope Tensioning-Sailing Column Type-11 3D model

License: Content published with the label may not be sold, given, or assigned to another person or entity in the form it is downloaded from the site.

author:

SUNVERRA

All content related to this 3D asset—including renders, descriptions, and metadata — is credited to its original author, «SUNVERRA». CGhub does not claim copyright ownership over the content used.

Steel Pedestrian Bridge

Sailing Column Type Construction

Two Column Consruction

Open Top Construction

Straigth Beam Type

Curved Column Type

Platfrom With Steel Rope Tensioning System

Named Objects

Largest Column Span : 48,74 mt.

Distance Between Two Columns : 48,74 mt.

Platform Asphalt Height : 6 mt.

Platform Width : 3 mt.

Steel Rope : 16 piece

Rope Fixed Press : 16 piece

Rope Tensioning Press System : 16 Piece

Column Raft Concrete : width 2,5 mt * length 6 mt. * height 1 mt.

Stairs Raft Concrete : width 1 mt * length 2,5 mt. * height 1 mt.

Tension Column Raft Concrete : width 2,5 mt * length 2,5 mt. * height 1 mt.

Stairs Straight Type

Rigth And Left Double Landing Stairs

Curved Landing

Bottom Stair Step Width : 1,8 mt.

Top Stair Step Width : 2,4 mt.

Step Sizes : 300 mm. * 150 mm.

Flat Railing Construction

Railings Box Profile

Platform And Columns With Bolted Connection

Walking Surface : 2 cm. Rubber Flooring

Prepared With BLENDER Version 2.93.5

Polygons : 171074

Vertices : 278956

Objects : 4206

3D Model details

cgtrader Platform
Animated
Rigged
Ready for 3D Printing
VR / AR / Low-poly
PBR
Textures
Materials
UV Mapping
Unwrapped UVs: Unknown
Geometry: Unknown
Polygons: 171074
Vertices: 278956

Tags

Architecture Ladder Bridge Rail Pedestrian Footbridge Steel Columns Beam Structure Building Overpass Road Roadway Render Outdoor Rubber Handrail Walk Engineering Architectural Pedestrian bridge Steel beam Steel structure
