Two-Wing Adjustable Incline Conveyor 3D model
Home Catalog Two-Wing Adjustable Incline Conveyor 3D model
Two-Wing Adjustable Incline Conveyor 3D model
Two-Wing Adjustable Incline Conveyor 3D model
Two-Wing Adjustable Incline Conveyor 3D model
Two-Wing Adjustable Incline Conveyor 3D model
Two-Wing Adjustable Incline Conveyor 3D model

Publication date: 2026-02-07

Two-Wing Adjustable Incline Conveyor 3D model

$48

License: Royalty Free

author:

KienThuc

All content related to this 3D asset—including renders, descriptions, and metadata — is credited to its original author, «KienThuc». CGhub does not claim copyright ownership over the content used.
Buy at www.cgtrader.com - $48 Add to Wishlist
  • Description
  • Formats

Application:

  • Designed for handling bagged or boxed bulk materials from ground level to trucks, from ground level to stacked heights, or in reverse.
  • Conveyor speed is optimized for manual loading/unloading by workers.
  • Suitable for small workshops, agricultural handling, and light industrial applications...

Technical Specifications

  • Belt type: Rubber conveyor belt
  • Belt width: 500 mm
  • Length per wing: 4.5 m
  • Maximum lifting height: 4.0 m
  • Conveyor speed: 0.5 m/s
  • Maximum load on belt: 300 kg
  • Truck bed penetration length: 1.0 m

Design Advantages

  • Simple mechanical structure, easy to fabricate and manufacture.
  • Low maintenance, easy inspection and repair.
  • Compact design, allowing easy movement and operation in narrow spaces.

Design LimitationsThe current design does not include limit switches, sensors, or safety mechanisms for lift height or travel limits.

Additional InformationIf you require:

  • Detailed fabrication drawings
  • Bill of Materials (BOM) for fabricated and standard components
  • Laser / plasma cutting and bending drawings
  • Customized conveyor parametersPlease contact us at: machcalc@gmail.com
IGE (IGES, filesize: 80.7 MB), STP (STEP, filesize: 40 MB), X_T (Parasolid, filesize: 27.4 MB), SLDPRT (SolidWorks, filesize: 103 MB)

3D Model details

  • cgtrader Platform
  • Animated
  • Rigged
  • Ready for 3D Printing
  • VR / AR / Low-poly
  • PBR
  • Textures
  • Materials
  • UV Mapping
  • Polygons: 0
  • Vertices: 0
  • Geometry: Unknown

Tags

Industrial Part Industrial part Two wing Adjustable Incline Conveyor Agricultural Handling Rubber Belt Machine Industrial machine
